Pin 1: Ground Pin 2: LTC In Pin 3: unit specific (e.g. PPF Out) Pin 4: unit specific (e.g. Sync Out) Pin 5: LTC Out |
The pins for Ground (Pin 1), LTC in (pin 2) and LTC out (pin 5) are utilized the same on all Lockits and all other manufacturers that use this connector for timecode interconnection.
Pins 3 and 4 are used for different functions and signals, depending on the exact model. Current units offer other features like serial communication or Sync and PPF on these pins.
Older units used to support tuning per Ambient 501 Controller (discontinued) via ASCII and tune reference signal. Consult the manual for a specific product to find more information if necessary.
